1) Descriptions of Spiral Bevel Gear
Spiral bevel gears are gears with helical tooth surfaces, used for power transmission between two intersecting shafts.
They have unique performance in terms of cost and efficiency.
2) Features of Spiral Bevel Gear
a) Lubrication requirements: There are clear requirements for the quality of lubricating oil and the lubrication cycle.
Appropriate lubrication can reduce tooth surface wear.
b) Wear monitoring: The condition of tooth surface wear can be detected by professional instruments.
The wear state affects the transmission performance.
3) Advantages of Spiral Bevel Gear
a) Although the initial investment is large, the efficient power transmission reduces energy consumption and saves operating costs.
b) The long service life reduces the downtime losses and maintenance costs caused by frequent replacements,
and the overall benefits are significant.
| Products | Spiral Bevel Gears |
| Custom Made | √ |
| Gear Profile Type | Gleason |
| Manufacturing | Gear Milling & Gear Teeth Grinding |
| Teeth Grinding | √ |
| Module (M) | 16 |
| Number of Teeth (Z) | 32 |
| Pressure Angle (α) | 20° |
| Lead Angle | 15° |
| Accuracy Grade | ISO 6 Grade |
| Heat Treatment | Carburizing |
| Surface Hardness | 58-62HRC |
| STEEL CODE GRADES COMPARISON |
| CHINA/GB | ISO | ГΟСТ | ASTM | JIS | DIN |
| 45 | C45E4 | 45 | 1045 | S45C | CK45 |
| 40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
| 20CrMo | 18CrMo4 | 20ХМ | 4118 | SCM22 | 25CrMo4 |
| 42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
| 20CrMnTi | | 18XГT | | SMK22 | |
| 20Cr2Ni4 | | 20X2H4A | | | |
| 20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
| 40CrNiMoA | | 40XH2MA/
40XHMA | 4340 | SNCM439 | 40NiCrMo6/
36NiCrMo4 |
| 20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 | |
Production Process
Forging Machining Cutting
Heat Treatment Grinding Inspection
